Husqvarna 346XPG Chain Saw with 45cm bar and Chain
Condition: Brand New.
Made in Sweden (Year of
manufacture - 2009)
The small XP?G -saw for professional logging,
where users demand rapid acceleration, maximum power and manoeuvrability.
Includes features like the side-mounted chain tensioner, fuel pump and Smart
Start? for easier starts, quick-release cylinder cover and rubber-mounted
carburettor. Equipped with heated handles.
Features:
Magnesium crankcase, Smart Start?, Three-piece crankshaft, LowVib?
Fuel pump
Fuel pump designed for easy starting.
Ergonomic grip
Angled front handle for better grip and natural working position.
Heated handles
Efficient heating coils in the front and rear handles make the saw more
comfortable to use in cold and damp conditions.
Snap-lock cylinder cover
Snap-lock cylinder cover saves time when changing spark plugs and cleaning.
Air Injection
Centrifugal air cleaning system for reduced wear and longer operating time
between filter cleanings.
Engine specification
|
Cylinder displacement |
50.1 cm? / 3.06 cu.inch |
|
Power output |
2.7 kW / 3.7 hp(I) |
|
Idling speed |
2700 rpm |
|
Maximum power speed |
9600 rpm |
|
Maximum recommended engine speed |
14700 rpm |
|
Cylinder bore |
44 mm / 1.73 inch |
|
Cylinder stroke |
32.5 mm / 1.28 inch |
|
Ignition system |
SEM AM50 |
|
Ignition module air gap |
0.3 mm / 0.01 " |
|
Spark plug |
NGK BPMR7A |
|
Electrode gap |
0.5 mm / 0.02 " |
|
Carburettor model name |
C3-EL32 |
|
Fuel tank volume |
0.5 lit / 1.06 US pint |
|
Oil tank volume |
0.28 lit / 0.59 US pint |
|
Oil pump type |
Adjustable flow |
|
Oil pump capacity |
6-10 ml/min |
Cutting equipment
|
Chain pitch |
.325" |
|
Recommended bar length, min-max |
33-50 cm / 13"-20" |
|
Chain speed at max power |
18.5 m/s / 60.7 fts |
Emission, vibration & noise data
|
Equivalent vibration level (ahv , eq)
front / rear handle |
2.4/3.6 m/s? |
|
Sound pressure level at operators ear |
106 dB(A) |
|
Guaranteed sound power level, LWA |
113 dB(A) |
Overall dimensions
|
Weight (excl. cutting equipment) |
5.1 kg / 11.2 lbs |
|
|
€585.00
